Home Use 3kw 5kw On Grid Solar Inverter One Phase Grid Connected Solar Power Inverter

  • 1
  • 2
  • 3

Brand Name : Gospell

Certification : IEC62109-1, IEC62109-2

Place of Origin : China

MOQ : 1

Price : US$290/pc

Payment Terms : T/T, Western Union

Supply Ability : 3000 Piece/Pieces Per Month

Delivery Time : 8-12 working days

Packaging Details : Carton Box or Wooden Box

Application : on-Grid Solar System

Output Voltage : L/N/PE, 220VAC, 230VAC, 240VAC

Output Frequency : 50Hz/60Hz

Size : 265X310X140 mm/330X312X170 mm

Inverter Efficiency : 97.6%/98.2%

MPPT Voltage Range : 80V-540V

Degrees of Protection : IP65

Input Voltage : 360V

Output Type : Single

Weight : 7.2kg/10kg

Contact Now

On Grid Inverter New Series Home Use 3KW 5KW One Phase Grid-connected Solar Power Inverter High Efficiency Inverter

Home Use 3kw 5kw On Grid Solar Inverter One Phase Grid Connected Solar Power Inverter

Home Use 3kw 5kw On Grid Solar Inverter One Phase Grid Connected Solar Power Inverter

Home Use 3kw 5kw On Grid Solar Inverter One Phase Grid Connected Solar Power Inverter
Product details​​​

​

Technical Data
Mercury-3K-S0
Mercury-5K-S0
Max. DC input power
3900W
6500W
Max. DC input voltage
550V
550V
Operation voltage range
80V-540V
80V-540V
Number of independent MPPT / strings per MPPT
1/1
2/1+1
MPPT max. current
13A
13A
AC Output Data
Rated output power
3kW
5kW
Max. output power
3.3kW
5.5kW
Rated output voltage
230V/180V-280V
Rated output frequency
50Hz,60Hz/±5Hz
Rated output current
13.1A
21.8A
Max. output current
14.5A
24A
Power factor
-0.8~+0.8(adjustable)
THDi
<3%(Nominal Output)
Grid system pattern
L+N+PE
Efficiency
Max. efficiency
97.6%
98.2%
Europe efficiency
96.8%
97.5%
Protection
Input DC switch
yes
Input over current protection
yes
DC reverse polarity protection
yes
Output over voltage protection
yes
Output over current protection
yes
Anti islanding protection
yes
Insulation impedance protection
yes
RCD detection
yes
General Data
Dimensions(W/L/H)in mm
265/310/140
330/312/170
Weight
7.2kg
10kg
Noise
<25dB
Operation temperature range
-25ºC~+60ºC
Heat dissipation mode
Natural
IP Class
IP65
Maximum altitude
4000m
Self-Consumption night
<1w
Topology
Transformerless
Features
LCD display
yes
Communication interface
WIFI/GPRS/RS485(optional)
Warranty
5 years (standard)
Standards
IEC62109-1,IEC62109-2,NB/T32004,VDE-AR-N4105,EN50549,AS 4777

​

Note:Technical parameters listed hereunder are for reference only. Actual parameters shall be subject to products shipped.

FAQ

Q1. Can I have a sample order for solar products?
A: Yes, we welcome sample orders to test and check quality. Mixed samples are acceptable.
On Grid Inverter New Series Home Use 1KW 3KW 5KW 8KW 10KW One Phase Grid-connected Solar Power Inverter High Efficiency Inverter
Q2. What about the lead time?
A: Sample needs 3-5 days, mass production needs 1-2 weeks for order quantity more than one container
On Grid Inverter New Series Home Use 1KW 3KW 5KW 8KW 10KW One Phase Grid-connected Solar Power Inverter High Efficiency Inverter
Q3: Are you a factory or a trading company?
A: We are the factory with high production capacity and product range of solar products in China.
On Grid Inverter New Series Home Use 1KW 3KW 5KW 8KW 10KW One Phase Grid-connected Solar Power Inverter High Efficiency Inverter
Q4: How do you ship the goods and how long does it take to arrive?
A: Sample shipped by DHL, UPS, FedEx, TNT, etc. It usually takes 3-5 days to arrive. Airline and sea shipping is also optional.
